eco PDU PE Series User Manual
80
PE6108G / PE6208G / PE8108G / PE8208G
Function PE6108G / PE8108G PE6208G/ PE8208G
Power Outlets Direct 8
Connectors Power Inlet 1 x IEC 320 C20
Power
Outlets
NEMA NA
IEC 8 x IEC 320 C13 7 x IEC 320 C13 (Ports 2–8);
1 x C19 (Port 1)
Sensor 2 x RJ-11
LAN 1 x RJ-45 (F)
LEDs Outlet Status 8 (Orange)
Selection 1-digit 7-segment (Orange)
PDU Current / Outlet
Current / IP Address
3 (Green)
Current / IP Address 3-digit 7-segment (Orange)
Power 1 (Blue)
Link 1 (Green)
LAN 1 (Orange / Green)
Sensor 2 (Green)
Switches Reset 1 x Semi-recessed Pushbutton
Power 1 x Non-fuse Breaker
I/P Rating 100–240V~; 50/60Hz; 10A 100–240V~; 50/60Hz; 16A
Load Capacity 2400W 3840W
O/P Rating Per
Port
C13 100-240V; 50/60Hz, 10A
C19 NA 100-240V~; 50/60Hz, 16A
Total 100-240V~; 50/60Hz, 10A 100-240V~; 50/60Hz, 16A
Environment Operating Temp.
0–50
o
C
Storage Temp.
-20–60
o
C
Humidity 0–80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 2.82 kg / 2.87 kg 2.79 kg / 2.87 kg
Dimensions
(L x W x H)
43.24 x 20.0 x 4.40 cm
