eco PDU PE Series User Manual

6 reset button This button is recessed and must be pushed with a thin

object, such as the end of a paper clip.



Press and release to reboot the device.



Press and hold for more that three seconds to reset

the eco PDU to its factory default settings

7 power LED The LED lights when the eco PDU is ready to operate.

8 grounding

terminal

The wire used to ground the unit connects here.

9 sensor ports External sensors plug into these two RJ-11 ports.

10 power socket The power cord that connects the unit to an AC power

source plugs in here.
