eco PDU PE Series User Manual
76
PE5108B / PE5208B / PE7108B / PE7208B
Function PE5108B / PE7108B PE5208B / PE7208B
Power Outlets Direct 8
Connectors Power Inlet 1 x IEC 320 C20
Power
Outlets
NEMA N/A
IEC 8 x IEC 320 C13 7 x IEC 320 C13 (Ports 2–8);
1 x C19 (Port 1)
Sensor 2 x RJ-11
LAN 1 x RJ-45 (F)
LEDs Outlet Status N/A
Selection 1-digit 7-segment (Orange)
PDU Current / Outlet
Current / IP Address
3 (Green)
Current / IP Address 3-digit 7-segment (Orange)
Power 1 (Blue)
LAN 10/100M 1 (Orange / Green)
Link 1 (Green)
Sensor 2 (Green)
Switches Reset 1 x Semi-recessed Pushbutton
Power 1 x Non-fuse Breaker
I/P Rating 100–240V~; 50/60Hz; 12A 100–240V~; 50/60Hz; 16A
Load Capacity 2880W 3840W
O/P Rating Per Port C13 100–240V~; 50/60Hz, 12A
C19 N/A 100–240V~; 50/60Hz, 16A
Total 100–240V~; 50/60Hz, 12A 100–240V~; 50/60Hz, 16A
Environment Operating Temperature
0–50
o
C
Storage Temperature
-20–60
o
C
Humidity 0–80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 2.70 kg / 2.73 kg 2.71 kg / 2.74 kg
Dimensions (L x W x H) 43.24 x 21.93 x 4.40 cm
