Chapter 4. Browser Operation

 Last Page:

Click to move to the last page of the log event list

 Export Log:

Click to save the contents of the log event list to file.

Notification Settings

The Notification Settings page is used to specify which of the eco PDU’s

components will receive notification of a log event. When you click the

Notification Settings menu item, a page similar to the one below appears:

 The event categories are listed in the left column.

 When you first open the page, only the main category items appear.

(Main category item rows have a gray background.)

 Subcategory items are nested under the main category headings. Click

the accordion in front of the main category headings to display the

subcategory items. (Subcategory item rows have a white background.)

 Click the checkboxes under the column headings to select which

component(s) will receive notification of the log events.

 Clicking on a main category heading’s row automatically selects all the

subcategory items nested below it.

 If you only want to set notification for some of the subcategory events,

don’t put a check in the main category row. Instead, drop down the

subcategory list, and only check the subcategory events you want.

 When you have finished making your setting choices, click Save. When a

specified log event occurs, notification of that event will be sent to the

selected component.

 Reset Digital Output:

If an event has been triggered that changes the digital output sensor from

Low to High, click this button to return the sensor to the Low state.
