1
Chapter 1
Introduction
Overview
The CAMLIVE™ PRO is designed to easily capture and mix the two connected
4K video sources in FHD format for livestream purpose with outstanding video
effects and remarkable image quality. This video capture device combines
video capture, encoding, and 2-channel video mixing and switching from HDMI
source and professional line-level audio device. It helps livestreaming become
unique and stand out from thousands of CDN videos. The CAMLIVE™ PRO
supports easy switch between multiple connected sources and combine them
for a rich information delivery in steaming. In addition, it automatically converts
the sources to clean-looking USB video format in 720P or 1080P, which is sent
to your laptop/smartphone via USB.
Easy to use – the CAMLIVE™ PRO provides an intuitive ATEN OnAir Lite App.
This App places everything you need to customize your video stream right at
your fingertips. Combine, crop, and scale video to make outstanding PnP
layouts. Preset up to 8 custom scenes and manage audio sources with the
intuitive touch panel interface for a superior pro-level finish. Open up a world of
possibilities by using the chroma keying. You can make it look like you are
anywhere by changing the background for eye-popping effects.
Providing smooth video streaming workflow for dual camera or single operator
setups, the CAMLIVE™ PRO allows any streamer to broadcast over internet
for higher quality livestream to major streaming services or remote conferencing
service such as YouTube Live, Facebook, OBS, Microsoft Teams, Microsoft
Mixer, Zoom, CameraFi, and Twitch. It enables eye-popping, high-quality one
stop programming streaming broadcasting capability with PC and Mac platform.
Whether you're capturing, editing or streaming, the CAMLIVE™ PRO is flexible
enough to fit all independent livestreaming broadcasting environments. This
micro device packs several features in one such as and its lightweight design
makes it possible to fit in any case and bring it to any live event. With just the
CAMLIVE™ PRO, companion app, and your laptop / smartphone, you have all
the devices you need to present engaging livestreaming that will rival the most
advanced streamers on social media and provides an easy-to-use solution.
