CAMLIVE™ PRO User Manual
2
Features
Mix and capture two unencrypted 4K live videos at 1080P UVC format on
PC or mobile device via USB 3.x interface with seamless transition
Intuitive Android / iOS App control – set up your camera gear and direct
your show from anywhere
Supports real-time HDMI program video preview
Easily identifiable chroma keys – can make the video look like you are
anywhere by changing the background
Provides audio mixer with additional dual analog audio inputs
Supports protected video (encrypted) switching mode for regular event
usage
Compatible with USB & Thunderbolt 3 (USB-C)
Planning the Installation
Requirements
Prepare the following before installing the CAMLIVE™ PRO unit:
2 HDMI source devices
1 HDMI display
1 XLR audio source
1 RCA audio source
1 mobile device (Android / iOS)
