CAMLIVE™ PRO User Manual
60
Upgrade Failed
If the Upgrade Succeeded screen doesn’t appear, it means that the upgrade
failed to complete successfully, in which case you should do the following:
1. Power off the CAMLIVE™ PRO by removing the power jack.
2. Invoke Firmware Upgrade Mode by holding down the Bluetooth link
pushbutton on the front panel (see HDMI 2 audio status LED, page 4), and
power on the CAMLIVE™ PRO. The front LEDs flash together.
3. Do the firmware upgrade procedure again.
