Chapter 1. Introduction
5
4 Bluetooth link
pushbutton
Press to quickly switch between scene 1 and scene 2.
Press and hold 3 seconds to disconnect the Bluetooth
connection between CAMLIVE™ PRO and your mobile
device.
Press and hold the Bluetooth link pushbutton, and power on
the CAMLIVE™ PRO to perform a firmware upgrade. See
Preparation, page 56.
Press and hold the Bluetooth link pushbutton, power on the
CAMLIVE™ PRO, and wait for 10 seconds to reset the unit.
See Using the OnAir Cam App, page 24.
Note:
All the LEDs blink at the same time to indicate that the firmware upgrade is in
progress.
The HDMI 1 video status LED and the HDMI 2 video status LED blink once every
0.5 seconds for 3 seconds when you disconnect the Bluetooth connection.
No. Component Description
