![SNR S2989G-48TX-DC [198/553] Keepalive gateway example](/views2/1978540/page198/bgc6.png)
S2989G-24TX Operation Manual
Chapter 3 IP services Configuration
3-36
2. Show keepalive gateway and IPv4 running status of interface
Command
Explanation
Admin and configuration mode
show keepalive gateway
[interface-name]
Show keepalive running status of the
specified interface, if there is no interface is
specified, show keepalive running status of
all interfaces.
show ip interface [interface-name]
Show IPv4 running status of the specified
interface, if there is no interface is specified,
show IPv4 running status of all interfaces.
3.13.3
Keepalive Gateway Example
Figure 3-8 keepalive gateway typical example
In above network topology, interface address of interface vlan10 is 1.1.1.1
255.255.255.0 for gateway A, interface address of interface vlan100 is 1.1.1.2
255.255.255.0 for gateway B, gateway B supports keepalive gateway function, the
configuration in the following:
1. Adopt the default interval that ARP packet is sent and the retry-count after detection is
failing (the default interval is 10s, the default retry-count is 5 times)
Switch(config)#interface vlan 100
Switch(config-if-vlan100)#keepalive gateway 1.1.1.1
Switch(config-if-vlan100)#exit
2. Configure the interval that ARP packet is sent and the retry-count after detection is
