S2989G-24TX Operation Manual
Chapter 8 Debugging and Diagnosis Configuration
8-25
2. For the source and intermediate switches in the RSPAN connections, the
native VLAN of TRUNK port cannot be configured as the RSPAN VLAN, Otherwise
the RSPAN tag will be disposed before reaching the destination switches.
3. The source port, in access or trunk mode, should not be added to RSPAN
VLAN if advanced RSPAN mode is chosen.
4. When configuring the remote mirroring function, the network bandwidth should
be considered in order to carry the network flow and the mirrored flow.
Keywards:
RSPAN: Remote Switched Port Analyzer.
RSPAN VLAN: Dedicated VLAN for RSPAN.
RSPAN Tag: The VLAN tag which is attached to MTP of the RSPAN datagrams.
Reflector Port: The local mirroring port between the RSPAN source and destination
ports, which is not directly connected to the intermediate switches.
8.7.2
RSPAN Configuration Task List
1. Configure RSPAN VLAN
2. Configure mirror source port
3. Configure mirror destination port
4. Configure reflector port
5. Configure remote VLAN of mirror group
1. Configure RSPAN VLAN
Command
Explanation
VLAN Configuration Mode
remote-span
no remote-span
To configure the specified VLAN as RSPAN
VLAN. The no command will remove the
configuration of RSPAN VLAN.
2. Configure mirror source port
Command
Explanation
Global Mode
monitor session <session> source
{interface <interface-list>} {rx| tx|
both}
no monitor session <session> source
{interface <interface-list>}
To configure mirror source port; The no
command deletes the mirror source port.
