4.Loosenthescrewsthatsecurethememoryslotcover1,thenremovethecover2.

5.Iftwomemorymodulesarealreadyinthememoryslots,removeamemorymoduletomakeroomfor

thenewonebypressingoutonthelatchesonbothedgesofthesocketatthesametime1.Then

removethememorymodule2.Savetheremovedmemorymoduleforfutureuse.

6.Findthenotchonthecontactedgesideofthememorymoduleyouareinstalling.

Attention:Toavoiddamagingthememorymodule,donottouchitscontactedge.

Chapter6.Replacingdevices79
