7.Withthenotchedendofthememorymoduletowardthecontactedgesideofthesocket,insertthe
memorymoduleintothesocketatanangleofabout20degrees1;thenpressitinrmly2.
8.Pivotthememorymoduledownwarduntilitsnapsintoplace.
9.Makesurethatthememorymoduleisrmlyxedintheslotandcannotbemovedeasily.
10.Reinstallthememoryslotcoverandtightenthescrewstosecureit.
11.Reinstallthebattery.See“Replacingthebattery”onpage72
12.Turnthecomputeroveragain.Connecttheacpoweradapterandallcables.
Tomakesurethememorymoduleisinstalledcorrectly,youcancheckthetotalamountofmemoryby
doingthefollowing:
1.Turnthecomputeron.
2.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.The
Installedmemoryitemshowsthetotalamountofmemoryinstalledinyourcomputer.
80UserGuide
