Maxwell MW-1183 BK [12/44] English

ENGLISH

Use the detachable cup (18) as a food con-

tainer. Make sure that the lids (17 and 19) are

closed tightly and the cover (20) is closed till the

clamp clicking. When carrying the cup (18) filled

with the liquid, hold it strictly in vertical position

(the cover (20) is on the top).

Note:

The level of products in the containers (5, 11,

16 and 18) should not exceed the maximal

level mark:

Chopper cup (5) – 1000 ml,

Detachable cup (18) – 500 ml,

Coffee grinder bowl (16) – 200 ml,

Chopper bowl – 300 ml.

Note:

For the consumer safety the unit is equipped

with special protection system that blocks

the unit if the containers (5, 11, 16, 18) are

set improperly on the motor unit. See the

corresponding chapter for recommenda-

tions for proper container (5, 11, 16, 18)

installation.

Operation modes:

Select the operation mode using the switch (2):

«1» (low speed) – for mixing of liquid products;

«2» (high speed) – for liquid and hard products;

«P» (pulse mode) – for processing of hard

products and ice.

Note: For operation in pulse mode turn the

switch (2) to the left and hold it.

To switch the unit off set the switch to the posi-

tion «0».

USING THE CHOPPER CUP (5)

WARNING:

Fix the knives block (4) in the base (3) and

install them into the chopper cup (5) before

using the unit. Make sure that all the details

are fixed properly.

Before installing the blender on the motor

unit make sure that the power plug is not

inserted into the socket.

1. Make sure that the sealing gasket is set on

the knives block (4).

2. Carefully install the knives block (4) into the

base (3) from the side of the thread till bump-

ing. Be very careful, the knife blades are

very sharp!

3. Place the cup (5) on the base (3) and rotate

the base (3) clockwise until bumping. To

avoid damages do not apply excessive effort

while tightening.

4. Set the chopper cup (5) on the motor unit (1).

To do this match ledges on the lower part of

the cup with grooves on the motor unit, press

on the cup and turn it clockwise till locking.

5. Put the food into the chopper cup (5).

6. Fix the plug cup (7) in the lid (6) opening:

insert till bumping and turn till locking.

7. Install the lid (6) on the chopper cup (5) so

the arrow on the lid is to the left from the

spout. Then turn the lid clockwise till lock-

ing, the arrow and the lid (6) openings will be

opposite the spout.

8. Insert the power plug into the mains socket.

9. Select the operation mode using the switch

(2).

10. During the operation you can add the

required ingredients through the lid (6) open-

ing after removing the plug cup (7).

11. After the unit operation, switch the unit off

and unplug it.

12. Remove the chopper cup (5) from the motor

unit (1) by pressing on it and turning it coun-

terclockwise.

13. Remove the lid (6) turning it counterclock-

wise and remove the products.

14. Clean the unit.

Note:

Products should be put into the chopper cup

before the unit is switched on. The level of

the products to process should not exceed

the maximal volume 1000 ml.

Attention! Do not remove the chopper cup

from the motor unit during operation.

USING THE FILTER (8)

1. Make sure that the silicone gasket is installed

on the knives block (4).

2. Carefully install the knives block (4) into the

base (3) from the side of the thread till bump-

ing. Be very careful, the knife blades are

very sharp!

3. Install the cup (5) on the base (3) and turn

till locking.

4. Set the chopper cup (5) on the motor unit

(1). To do this match ledges on the lower

part of the cup with grooves on the motor

unit, press on the cup and turn it clockwise

till locking.

5. Install the filter (8) into the cup (5) with wide

side down. The grooves of the filter should

match the guideways inside the cup.

6. Install the lid (6) on the cup (5) in such way

that the arrow on the lid is to the left from the

MW-1183.indd 12 20.02.2014 15:48:26
