ENGLISH

USING THE COFFEE GRINDER

Use the coffee grinder bowl (16) with the knives

block (15).

WARNING:

Fix the knives block (15) in the base (14) and

install them into the coffee grinder bowl (16)

before using the unit. Make sure that all the

details are fixed properly.

Before installing the coffee grinder bowl on

the motor unit, make sure that the power

plug is not inserted into the socket.

1. Make sure that the sealing gasket is set on

the knives block (15).

2. Carefully install the knives block (15) into the

base (14) on the side of the screw thread

till bumping. Be very careful, the knife

blades are very sharp!

3. Place the bowl (16) on a flat surface and add

the products for grinding.

4. Install the base (14) with the knives block

(15) on the coffee grinder bowl (16) and turn

till locking.

5. Set the coffee grinder bowl (16) with the base

(14) installed on the motor unit (1). To do this

match ledges on the lower part of the bowl

with grooves on the motor unit, press on the

cup and turn it clockwise till locking.

6. Insert the power plug into the mains socket.

7. Select the operation mode using the switch (2).

8. After the unit operation, switch the unit off

and unplug it.

9. Remove the bowl (16) from the motor unit

(1) by pressing on it and turning it counter-

clockwise.

10. Turn up the bowl (16) and place it on a flat

surface. Unscrew the base (14) by rotating it

counterclockwise. Put the products into suit-

able container.

11. Clean the unit.

Notes:

The amount of processed products should

not exceed the maximal volume 200 ml.

Put no more than 100 g of coffee beans in the

coffee grinder at a time.

Do not remove the coffee grinder bowl (16)

during the operation.

USING THE CHOPPING KNIFE (12)

Process no more than 250 g of meat at a time.

Before you start chopping:

• Remove bones, sinews and cartilage from

meat.

• Cut meat, onion, garlic, carrots etc. into

approximately equal slices.

• When chopping greens, remove stems of

herbs.

ATTENTION: Before assembling the chopper

make sure that the power plug is not inserted

into the socket.

Caution! The chopping knife (12) is very

sharp! Always hold the knife only by the

upper plastic end.

1. Fix the gear (10) in the lower part of the

chopper bowl (11). To do this put ledges on

the gear between grooves on the lower part

of the bowl and turn the gear clockwise till

locking.

2. Holding the knife (12) by the upper plastic

end, install it on the gear (10) axis above the

bowl (11). Rotate it around its own axis till it is

in the proper position. The knife is installed

properly if its cutting edge is placed as close

to the bowl bottom as possible and it takes a

slight effort to rotate it. Attention! Always

hold the chopping knife only by the upper

plastic end!

3. Put the products into the bowl (11).

4. Place the lid (13) on the bowl (11), press

on the lid and rotate it clockwise until lock-

ing. Make sure that all 4 clamps are closed

properly.

5. Set the bowl (11) on the motor unit (1).

To do this match ledges on the lower part

of the bowl with grooves on the motor unit,

press on the bowl and turn it clockwise till

locking.

6. Switch the unit on with the switch (2).

7. During the operation hold the chopper bowl

(11) with one hand.

8. After you finish using the chopper, switch the

unit off and unplug it.

9. Remove the blender bowl (11) from the motor

unit (1) by pressing on it and turning it coun-

terclockwise.

10. Remove the lid (13) rotating it counterclock-

wise.

11. Carefully remove the knife (12) taking it by

the upper plastic end.

12. Take the chopped products out of the chop-

per bowl (11).

13. Clean the unit.

Attention! Strictly follow the described

sequence of operations.

Volume of the products should not exceed

300 ml.
