APart MA200 [12/16] Technical specifications

WWW.APART-AUDIO.COM

FREQUENCY RESPONSE 40HZ 25KHZ (+1/-3 DB)

DISTORTION <0,3% @ -6DB, 1KHZ

BASS CONTROL +/- 10DB, 100 HZ

TREBLE CONTROL +/- 10DB, 10 KHZ

S/N amplier: better than 95dB, 22Hz 22kHz

line: better than 80dB, 22Hz 22kHz

mic: better than 65dB, 22Hz 22kHz

LED INDICATORS limiter active, red

signal 100%, yellow

signal -25 dB, green

power on, green

protection active, red

ZONE ACTIVE INDICATORS Z1, Z2 and Z3 green LED

Z4 music on/off, orange

Z4 paging allowed on/off, orange

MUTED BY PRIORITY LED any of the priority modes active, red

POWER SUPPLY 230V/ 50-60HZ MAX750VA

WEIGHT approx.12,7 kg

DIMENSIONS 430(W) x 88(H) x 356(D)mm

19” wide, 2U high

OPERATING TEMPERATURE -10 to +45°C

8. Technical Specifications

General
