SpeakeR SeLectoR

ZONE 1 3 on/off

ZONE 4 paging on/off music on/off

SpeakeR zone output, euRo bLock

HIGH Z ZONE 1-2-3-4 100 V

SpeakeR out; euRo bLock

HIGH Z 50 (12,5 Ω) 70 (24,5 Ω) 100 V (50 Ω)

LOW Z 8 Ω

phantoM poweR

MIC 1-2-3-4 14 V; internal jumpers

pRe aMp out

LEVEL 1 V

RecoRD out; Rca Mono

LEVEL 1 V

pRioRity out

LEVEL 24 V DC; max 1A, short circuit protected

chiMe

2 tone

activated by contact closure;

euro block DIN5

on/off and level set by trimmer

pRioRity

I Emergency input / telephone

200 mV; 1 kHz VOX threshold

mutes all other signals

> 40 DB

II Vox mute only for mic 1

0,6 mV; 1 kHz VOX threshold

mutes mic 2,3 & 4 + music

on/off/level set by trimmer

> 40 dB

III

Priority contact

> 40 dB

mutes all music inputs

Outputs
