MIC INPUT 1; ¼” TRS PHONE JACK AT THE FRONT

XLR3 COMBO, DIN5; EURO BLOCK

SENSITIVITY 1,5 MV

IMPEDANCE 600 Ω

S/N (AT MAX. VOLUME) > 65 dB

PHANTOM POWER 14 V (internal jumper)

FREQUENCY RESPONSE > 80Hz->15Khz (+1/-3 dB)

VOX MUTE trigger level 0,6 mV, 1Khz, mutes mic 2,3,4+music, > 40 dB

Mic input 2,3 & 4: XLR3 balanced

SENSITIVITY 1,5 mV

IMPEDANCE 600 Ω

S/N (AT MAX. VOLUME) > 65 dB

PHANTOM POWER 14 V (internal jumper)

FREQUENCY RESPONSE > 80Hz->15Khz (+1/-3 dB)

Emergency input; euro block

SENSITIVITY 1 V

IMPEDANCE 600 Ω

S/N (AT MAX. VOLUME) > 80 dB

FREQUENCY RESPONSE > 100Hz-> 25Khz (+1/-3 dB)

MUTE mutes all, > 40 dB

AUX INPUT; RCA

SENSITIVITY 500 MV (-6 DB)

IMPEDANCE 22 KΩ

S/N (AT MAX. VOLUME) > 80 DB

FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)

LINE 4; RCA

SENSITIVITY 200 MV (-14 DB)

IMPEDANCE 47 KΩ

S/N (AT MAX. VOLUME) > 80 DB

FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)

CD IN

SENSITIVITY 500 MV (-6 DB)

IMPEDANCE 5 KΩ

S/N (AT MAX. VOLUME) > 80 DB

FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)

TUNER

SENSITIVITY 300 MV (-6 DB)

IMPEDANCE 30 KΩ

S/N (AT MAX. VOLUME) > 80 DB

FREQUENCY RESPONSE > 40HZ-> 25KHZ (+1/-3 DB)

Inputs
