Braun TS340С [9/60] D after ironing
![Braun TS340С [9/60] D after ironing](/views2/1994993/page9/bg9.png)
9
The temperature selector (6) has to be set
between «••» and «max».
Preconditioning
Steam also develops horizontally at the front
area of the sole plate. This preconditions the
textiles by «pre-steaming», thus making ironing
easier.
Be careful – steam comes out laterally.
2 Power shot
Prior to use, press the Power shot button (5)
3 to 4 times to activate it.
Press the Power shot button in intervals of at
least 5 seconds.
Power shot can be activated when dry ironing.
The temperature selector has to be set
between «•••» and «max».
The Power shot function can also be used in the
vertical position for steaming hanging clothes.
3 Spray function
Press the spray button (4).
4 Dry ironing
Set the steam regulator (3) on position «0»
(= steam off).
D After ironing
Unplug the iron and turn the steam regulator to
position «0». To prolong the life of the iron,
empty the water tank. Store the cool iron in a
dry place always standing on its heel rest.
E Maintenance and cleaning
To prevent damaging the sole plate, do not iron
over metal buttons or zippers. Clean the sole
plate regularly with a damp cloth. To remove
mineral/starch residues, use a vinegar/water
mixture in the ratio of 1
:
2. Never use steel wool,
abrasive scouring pads, powders or other
chemicals to clean the sole plate.
F Cleaning the anticalc valve
The anticalc valve located on the lower end of
the steam regulator (3) has to be decalcified
regularly (e.g. whenever steam development is
insufficient). For this, the water tank has to be
empty.
Removing the steam regulator with the anticalc
valve:
Turn the steam regulator clockwise towards
.
Keep on turning firmly beyond the resistance
until the steam regulator is lifted. When
positioned at «•» (anticalc system), pull it out
vertically. Do not touch the anticalc valve at its
lower end. Immerse the anticalc valve in vinegar
(not vinegar essence) or lemon juice for a
minimum of 30 minutes. Brush off remaining
residues and rinse under running water
(fig. F 1–5).
Re-inserting the steam regulator:
When re-inserting the steam regulator, make
sure the steam regulator base still points on
setting «•» (anticalc system) (fig. F 6). When
firmly pushing down the steam regulator, it turns
back to
(fig. F 7) where it catches.
Notice: The iron must never be used without
steam regulator.
G Decalcifying / anticalc system
In order to clean the steam chamber from
residues, decalcify it as shown in picture section
G 1–11.
Caution: Hot water and steam will come out
from the sole plate when the steam regulator is
turned clockwise beyond
.
Wait for the sole plate to cool down, then clean
it as described above.
Then refill the tank with water, heat up the iron
and press the Power shot button four times to
rinse the iron before ironing (fig. G 12–14).
Do not use commercial decalcifiers, they may
damage the iron.
Trouble-shooting guide
Problem Remedy
Drops coming out of
the steam vents
Turn the steam regulator
anti-clockwise to reduce
the steam or turn it off.
Take longer intervals when
pressing the Power shot
button.
Select a higher tempera-
ture setting.
Less steam develops
or no steam at all
Check water level. Clean
the anticalc valve.
Calcium particles
coming through
the steam vents
Decalcify the steam
chamber.
Subject to change without notice.
Please do not dispose of the product in the
household waste at the end of its useful life.
Disposal can take place at a Braun Service
Centre or at appropriate collection points
provided in your country.
5712710104_TexStyle_340-320_S06-60.indd 95712710104_TexStyle_340-320_S06-60.indd 9 09.01.14 13:5409.01.14 13:54
