Falmec Lumiere 67 (450) (с системой E.ion) ECP [15/64] Electrical connections
![Falmec Lumiere 67 (450) (с системой E.ion) ECP [15/64] Electrical connections](/views2/1997024/page15/bgf.png)
13
Before performing any cleaning or maintenance operations, disconnect the appliance by un-
plugging it or using the main switch. The manufacturer disclaims all liability for any damage
that may be directly or indirectly caused to people, things and animals due to the failure to
follow all the instructions provided in this booklet and above all the warnings relating to the
installation, operation and maintenance of the appliance.
- there is a fire risk if cleaning is not carried out in accordance with the instructions.
CAUTION: Accessible parts may become hot when used with cooking appliances.
WARNING: Failure to install the screws or fixing device in accordance with these instructions
may result in electrical hazards.
Warning only for Australia: hood width less than 90 cm: use max. 4 hobs
TECHNICAL SPECIFICATIONS
B
The technical data pertaining to the electric appliance The technical specifications of the ap-
pliance are shown on the rating plates located inside the range hood.
INSTALLATION
C
The distance between the hob and the lowest part of the range hood is normally at least 65 cm
(see figure C1). This distance is measured in the lowest part of the range hood not operating
at safety voltage. Based on this detail provided by European Standards, the distance may be
reduced in some models as specified in the general catalogue. Should the instructions of the
gas cooker specify a greater distance, take this into consideration.
The filtering E-ION range hoods are with air recirculation system do not require an exhaust air
connection. For the combined and regenerable Carbon.Zeo filter maintenance see section H.
Assembly instructions: see section “O” of the booklet.
ELECTRICAL CONNECTIONS
D
ATTENTION! Disconnect the appliance from the mains before performing any kind of opera-
tion inside the hood range. Ensure that the wires inside the range hood are not disconnected
or cut; if this is the case, contact your nearest After-Sales Service. Electrical connections
must be performed by qualified personnel.
Connection must be performed in compliance with the standards in force.
Verify that the electrical system can support the load of the appliance (see technical data plate
in section B). The E-ION range hoods are usually supplied without plug and with power cable
with transparent sheath where the main insulation of the earth cable is yellow/green.
The appliance must be connected downstream a disconnection device conforming to the III
over-voltage category and national installation rules.
The yellow/green earth cable must be interrupted by the switch.
Before connecting the appliance to the mains, verify that:
- the power voltage corresponds to that indicated in the data plate.
- the earth socket is correct and functional.
- the power supply system has an efficient earth connection according to the standards in
force.
- the omnipolar socket or switch can be accessed easily with the appliance installed.
The manufacturer declines any liability in the event safety standards are not complied with.
English
