SELECT
MODE
CHNS
A B
DOUBLE
1-24 SINGLE
PRESET
PRESET
SCENES
2.2 Editing
2.2.1 Edit Enable
2. Operation Guide
1. Record enable.
2. Use the Page button to select the page the
program you wish to edit is on.
4. Press and hold down the Edit button.
3. Tap the Mode Select button to select
CHNS SCENES.
PAGE
EDIT
1 2 3 4
11
