AMERICAN DJ Scene Setter 24 [34/38] Brief of main functions
![AMERICAN DJ Scene Setter 24 [34/38] Brief of main functions](/views2/2008156/page34/bg22.png)
4. Brief of Main Functions
The ADD/KILL Button changes the mode of the flash buttons. Normally the flash buttons
are in Add mode, whereas pressing any flash button will not kill other scenes, allowing
multiple scenes to be on at a time.
The Kill mode is activated by pressing the Add/Kill button and illuminating the LED
above it. Pressing any flash button will kill other active SCENE or Program.
In Kill Mode, the killed program does not stop running but can not output.
Add and Kill
1. In CHNS SCENES Mode, press down the button you can change the chasing
mode of programs between Single Mode and Mix Mode.
2.In Double Preset Mode, pressing down this button is equal to pushing Master Slider B
to the top.
3.In Single Preset Mode, this button could temporally record current output, with
Master Slider B to adjust.
Park
1. Enter the Double Preset Mode.
2. Push Channel Sliders 1 to 6 to the top and move Channel Sliders 19 to 24 to the
maximum.
3. Move Master A and B to the same level and push them to the same direction, you
will get a scene.
Example
1. Press Mode Select Button to enter A Double Preset Mode.
2. In this mode, Channel Sliders 1-12 and channel sliders 13-24 both control Channel
1-12
3. Master A controls channel Slider 1-12 while Master B controls Channel Sliders 13-24.
4. In this Mode, no scene could be recorded.
Double Preset
.
31
