AMERICAN DJ Scene Setter 24 [33/38] Brief of main functions

1. Will run all programs synchronously.

2. All programs can be controlled by the same SLIDER SPEED, or each programs

speed may be controlled individually. (See Speed Setting ).

3. Press the MODE SELECT BUTTON and select "CHNS SCENES".

4. Press the PARK BUTTON to select MIX CHASE MODE. A yellow LED will

indicate this selection.

4. Brief of Main Functions

1. The 3-Digit Segment Display is used to display intensity percentage or absolute

DMX value.

2. To change between percentage and absolute value:

Press and hold the Shift Button. While holding down the Shift button press the

% or 0-255 Button to switch between percentage and absolute values.

3. If the Segment Display reads, for example, "076", it means a percentage value 76%.

If the Segment Display reads "076.", it means the DMX value 76.

Dimmer Display

Mix Mode

Blind and Home

1. Blind function takes channels temporally out from a chase, when the chase is running,

and gives you manual control over the channel.

2. Press and hold the Blind Button and tap the relative Flash Button you want to temporarily

take out of the chase.

3. To return to normal chase again press and hold the Home Button and push the Flash

Button you want to return to normal chase.

1. All programs will run in sequential order starting in the order of program number.

2. The Segment Display will read the running program number.

3. All programs will be controlled by the same Speed Slider .

4. Press the MODE SELECT BUTTON and select " CHNS SCENES".

5. Press the PARK BUTTON to select SINGLE CHASE MODE. A red LED

will indicate this selection.

Single Mode
