AMERICAN DJ Scene Setter 24 [37/38] Technical specifications
![AMERICAN DJ Scene Setter 24 [37/38] Technical specifications](/views2/2008156/page37/bg25.png)
Technical Specifications
Power Input .............................................. DC 12~20V, 500 mA min.
DMX Output .......................................................... 3 pin female XLR
MIDI Signal ................................................. 5 pin standard interface
Audio Input ................................................................ 100 mV~1Vpp
Fuse(internal) .................................................. F0.5A 250V 5x20mm
Dimensions .............................................................. 482x264x85mm
Weight(appro.) ........................................................................ 4.6 kg
Attention!
1. To retain your programs from loss, this unit must be powered not less
than two hour every month.
2. The Segment Display shows "LOP" if the voltage is too low.
34
