ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 30
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to control the chases and patterns, dimmer
and strobe. A DMX controller allows you to create unique programs
tailored to your individual needs.
1. The Focus Spot Three Z has 2 DMX channel modes; 18 channel
mode, and 21 channel mode. See pages 12-19 for detailed
description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 9-11 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 21 to select your desired DMX
channel mode and to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows either single unit or several
units linked together, to run to the beat of the music.
1. Press the MENU button until “Sound State” is displayed, and
press ENTER. Press the UP or DOWN buttons so that “ON” is dis-
played and press ENTER.
2. Press the MENU button until “Sound Sense” is displayed, and
press ENTER. Use the UP and DOWN buttons to adjust the sound
sensitivity. Press ENTER when you have found your desired sensi-
tivity level.
Show Mode: This mode allows either a single unit or several units
linked together, to run one of four shows that you choose.
1. Press the MENU button until “Show Mode” is displayed, and
press ENTER.
2. Press the UP or DOWN buttons to nd your desired show, and
press ENTER.
Focus Spot Three Z Operation
ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 31
Focus Spot Three Z Home Adjustment Menu
Prism 2 Oset - Setting adjustment for the 2nd prism.
1. Press the ENTER button for at least 5 seconds, then press the
UP or DOWN buttons so that “Prism 1 Offset” is displayed, press
ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
Rprism Oset - Setting adjustment for the rotating
prism.
1. Press the ENTER button for at least 3 seconds, then press the
UP or DOWN buttons so that “Rprsim Offset” is displayed, press
ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
Focus Oset - Setting adjustment for the focus.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “Focus Offset” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
Zoom Oset - Setting adjustment for the zoom.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “Zoom Offset” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
