AMERICAN DJ Focus Spot THREE Z [2/20] Caution
![AMERICAN DJ Focus Spot THREE Z [2/20] Caution](/views2/2008199/page2/bg2.png)
ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 3ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 2
• DMX-512 Protocol Compatible (2 DMX Channel Modes: 18 Chan-
nels & 21 Channels)
• 3 Operating Modes - Sound Active, Show Mode, & DMX Control
• 5 Dimmer Curves (Standard, Stage, TV, Architectural, & Theatre)
• Internal Microphone
• Digital Display for Address and Function Setting
• 4 Preprogrammed Shows
• UC IR and Airstream IR Compatiable (Not Included)
Focus Spot Three Z Features
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ Products, LLC.
During operation the housing may become extremely hot. Avoid
touching the unit with bare hands while in use.
ADJ Products, LLC will not accept any liability for any resulting dam-
ages caused by the non-observance of this manual or any unauthor-
ized modication to this unit.
Focus Spot Three Z Handling Precautions
Focus Spot Three Z Warranty Registration
The Focus Spot Three Z carries a 2 year (730 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase
and warranty. You may also register your product online at www. adj-
products.com. All returned service items whether under warranty or
not, must be freight pre-paid and accompany a return authorization
(R.A.) number. If the unit is under warranty you must provide a copy
of your proof of purchase invoice. Please contact ADJ Products, LLC
customer support for a R.A. number.
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
Focus Spot Three Z General Instructions Focus Spot Three Z General Information
Unpacking: Thank you for purchasing the Focus Spot Three Z by
ADJ Products, LLC. Every Focus Spot Three Z has been thoroughly
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
xture for any damage and be sure all equipment necessary to oper-
ate the unit has arrived intact. In the event damage has been found
or parts are missing, please contact our toll free customer support
number for further instructions. Please do not return this unit to your
dealer without contacting customer support rst.
Introduction: The Focus Spot Three Z is a DMX intelligent, moving
head, mini LED was. The Focus Spot Three Z can operate as a stand
alone fixture or in a Master/Slave set up. The Focus Spot Three Z has
three operating modes; a sound active, show mode, DMX controlled.
This fixture is suitable for theaters, studios, retail stores, and other
similar locations. For best results use fog or special effects smoke to
enhance the beams projections.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
