AMERICAN DJ Focus Spot THREE Z [7/20] Channel value function
![AMERICAN DJ Focus Spot THREE Z [7/20] Channel value function](/views2/2008199/page7/bg7.png)
ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 12 ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 13
Focus Spot Three Z 18 Channel Mode
Channel Value Function
1 0 - 255 PAN MOVEMENT 0° - 540°
2 0 - 255 TILT MOVEMENT 0° - 270°
3 COLOR
0 - 7 WHITE
8 - 14 RED
15 - 21 ORANGE
22 - 28 YELLOW
29 - 35 GREEN
36 - 42 BLUE
43 - 49 PURPLE
50 - 56 LIGHT BLUE
57 - 63 PINK
64 - 127 COLOR MIXING
128 - 189 COUNTER CLOCKWISE ROTATION
FAST - SLOW
190 - 193 STOP
194 - 255 CLOCKWISE ROTATION SLOW - FAST
4 GOBOS (STATIC)
0 - 7 OPEN
8 - 15 GOBO 1
16 - 23 GOBO 2
24 - 31 GOBO 3
32 - 39 GOBO 4
40 - 47 GOBO 5
48 - 55 GOBO 6
56 - 63 GOBO 7
64 - 72 GOBO 1 SHAKE
73 - 81 GOBO 2 SHAKE
82 - 90 GOBO 3 SHAKE
91 - 99 GOBO 4 SHAKE
100 - 108 GOBO 5 SHAKE
109 - 117 GOBO 6 SHAKE
118 - 127 GOBO 7 SHAKE
128 - 189 COUNTER CLOCKWISE ROTATION
FAST - SLOW
190 - 193 STOP
194 - 255 CLOCKWISE ROTATION SLOW - FAST
Focus Spot Three Z 18 Channel Mode
Channel Value Function
5 GOBOS (ROTATING)
0 - 9 OPEN
10 - 18 GOBO 1
19 - 27 GOBO 2
28 - 36 GOBO 3
37 - 45 GOBO 4
46 - 54 GOBO 5
55 - 63 GOBO 6
64 - 73 OPEN
74 - 82 GOBO 1 SHAKE
83 - 91 GOBO 2 SHAKE
92 - 100 GOBO 3 SHAKE
101 - 109 GOBO 4 SHAKE
110 - 118 GOBO 5 SHAKE
119 - 127 GOBO 6 SHAKE
128 - 189 COUNTER CLOCKWISE ROTATION
FAST - SLOW
190 - 193 STOP
194 - 255 CLOCKWISE ROTATION SLOW - FAST
6 GOBO WHEEL 2 GOBO ROTATION
0 - 127 INDEXING
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 NO ROTATION
194 - 255 COUNTER-CLOCKWISE ROTATION
SLOW - FAST
7 PRISM
0 STOP
1 - 126 6 FACET PRISM
127 NO EFFECT
128 - 255 LINEAR PRISM
8 PRISM ROTATION
0 - 3 STOP
4 - 127 COUNTER CLOCKWISE ROTATION
FAST - SLOW
128 - 131 STOP
132 - 255 CLOCKWISE ROTATION SLOW - FAST
