NOTE: In a Master/Slave conguration you can make one

xture the Master and then set the next xture to “Slave 2”, the

xtures will now have contrast movement to each other.

Show Mode - Show modes 1 - 4 (Factory Shows).

1. Press the MENU button until “Show Mode” is displayed, press

ENTER.

2. “Show X” will now be displayed, “X” representing a number

between 1-4. Press the UP or DOWN buttons to nd your desired

2. Either “On” or “O” will now be displayed. Use the UP or

DOWN buttons to toggle between “On” and “O”.

3. Press ENTER to conrm your selection, the press and hold the

MENU button to activate.

Sound Sense - In this mode you can adjust the sound

sensitivity of the sound active mode.

1. Press the MENU button until “Sound Sense” is displayed,

press ENTER.

2. Press the UP or DOWN buttons to adjust the sensitivity level.

The sensitivity level can be adjusted between 0 (the lowest) and

this as the operating mode you would like the unit to return

to when power is applied.

1. Press the MENU button until “DMX State” is displayed, press

ENTER.

2. Either “Master/Slave”, “Blackout”, or “Last State” will be dis-

played. Choose an operating mode you would like the unit to

start up in when power is applied or the DMX signal is lost.

• Master/Slave - If the DMX signal is lost or power is applied, the

unit will automatically go into Master Slave mode.

• Blackout - If the DMX signal is lost or power is applied, the unit

curve.

1. Press the MENU button until “Dimmer Curve” is displayed,

press ENTER.

2. The current dimmer curve setting will be displayed.

3. Press the UP or DOWN buttons to nd your desired dimmer

curve and press ENTER to conrm. See the Dimmer Curve Chart

on page 22 for the settings.
