AMERICAN DJ Focus Spot THREE Z [20/20] Auto sensing voltage
![AMERICAN DJ Focus Spot THREE Z [20/20] Auto sensing voltage](/views2/2008199/page20/bg14.png)
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Focus Spot Three Z Specifications
Model: Focus Spot Three Z
Voltage: 100 - 240V, 50/60Hz
LED: 1 x 100W Cold White LED
Power Consumption: 230W
Dimensions: 7.25”(L) x 11.25”(W) x 19.75”(H)
183mm x 284mm x 489mm
Weight: 26 Lbs. / 12 kgs.
Beam Angle: 12-18 Degrees
Fuse: 5 Amp
Power Cord Daisy Chain: 3 Fixtures Max. (120V)
6 Fixtures Max. (230V)
Duty Cycle: None
DMX: 2 DMX Channel Modes: 18 Channel
Mode & 21 Channel Mode
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 2 Year (730 days)
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
The Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
ADJ Products, LLC - www.adj.com - Focus Spot Three Z Instruction Manual Page 38
