Screw one clamp via a M12 screw and nut to the included
bracket. Attach the bracket using the omega locks to the
bottom of the Focus Spot Three Z. Attach and pull the safety-
cable through one of the safety holes located on the bottom
base and over the trussing system or a safe xation spot. Insert
the end in the carabine and tighten the safety screw.
NOTICE: The suitable enviromental temperature for this light-
ing xture is between -25˚ C to 45˚ C. Do not place this lighting
xture in an enviroment where the temperatures are under or
above the temperatures stated above. This will allow the xture
to run at its best and help prolong the xture life.
Focus Spot Three Z Mounting Focus Spot Three Z CAD Drawing
489mm/19.25”
284mm/11.1’
183mm/7.20”
