ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 26 ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 27
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to control the pan, tilt, gobos, colors, focus-
ing, dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs.
1. The Focus Spot Two has 2 DMX channel modes; 15 channel
mode and 17 channel mode. See pages 12-17 for detailed
description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 9-11 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 21 to select your desired DMX
channel mode and to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows either single unit or several
units linked together, to run to the beat of the music.
1. Press the MENU button until “Sound State” is displayed, and
press ENTER. Press the UP or DOWN buttons so that “ON” is dis-
played and press ENTER.
2. Press the MENU button until “Sound Sense” is displayed, and
press ENTER. Use the UP and DOWN buttons to adjust the sound
sensitivity. Press ENTER when you have found your desired sensi-
tivity level.
Show Mode: This mode allows either a single unit or several units
linked together, to run one of four shows that you choose.
1. Press the MENU button until “Show Mode” is displayed, and
press ENTER.
2. Press the UP or DOWN buttons to nd your desired show, and
press ENTER.
Focus Spot Two Operation Focus Spot Two Master-Slave Set Up
Master-Slave Operation This function will allow you to link up to 16
units together and operate without a controller. The units will be sound
activated. In Master-Slave operation one unit will act as the controlling
unit and the others will react to the controlling units programs. Any unit
can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit press the MENU button until “Slave Mode” is
displayed, and press ENTER. Use the UP and DOWN buttons to
scroll to the “Master” setting and press ENTER.
3. After setting the Master unit to the master setting find and set
your desired operating mode.
4. On the slave units press the MENU button until “Slave Mode” is
displayed, and press ENTER. Choose either “Slave 1” or “Slave
2” and press ENTER.
5. The slave units will now follow the Master unit.
With this feature you can connect the xtures to one another
using the PowerCon input and output sockets. The quantity that
can be connected is 14 xtures maximum @ 120V and 26 xtures
maximum @ 230V. After you have reached the maximum amount
of xtures you will need to use a new power outlet. They must be
the same xtures. DO NOT mix xtures.
Focus Spot Two Power Cord Daisy Chain
Focus Spot Two Manual Focus
The focus can be adjusted under DMX control. It can also be manu-
ally focused using the focus wheel located on the bottom front of the
moving head. Rotate the focus wheel back and forth until you get your
perfect focus. This wheel can be used in conjunction with the focus
channel in DMX mode as well.
