ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 28
ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 29
The UC IR (sold separately) infrared remote gives you control of
various functions (See below). To control the fixture you must aim the
remote at the front of the fixture and be no more than 30 feet away.
The Airstream IR (sold separately) remote transmitter plugs into
the headphone jack of your iOS phone or tablet. To control your IR
fixture you must raise the volume to the maximum on your iOS phone
or tablet and aim the transmitter at the fixture sensor and be no more
than 15 feet away. After you have purchased the Airstream IR trans-
mitters, the app is a free download from the app store for your iOS
phone or tablet. The app comes with 3 pages of control depending
on the fixture you are using. Please see below for IR functions. This
unit works with App page 1.
STAND BY - Pressing this button will blackout the fixture.
FULL ON - Hold this button down to fully light up the unit. When you
let the button go, the unit will return to its previous state.
FADE/GOBO - Press this button once to access gobo wheel. Use
the number buttons to find your desired gobo.
“DIMMER +” and “DIMMER -” - Use these buttons to adjust the out-
put intensity in Color mode.
STROBE - This button will activate the strobe effect. Press and hold
this button to activate strobing and release the button to stop strob-
ing.
COLOR - Press this button to access the color wheel. Use the num-
ber buttons to select your desired color. Adjust the output intensity
using the “DIMMER +” and “DIMMER -” buttons.
1-9 - In color mode and gobo mode, these buttons will allow you to
select a desired color or gobo. In show mode buttons 1-4 will let you
select your desired show.
SOUND ON & OFF - These buttons activate and deactivate the
sound active mode.
SHOW - This activates the show mode. Use buttons 1-4 to select
your desired show.
Focus Spot Two Remote Operation
The gobo’s in this unit are interchangable. Please be very care-
ful when replacing the gobo.
Caution! Never open the unit when in use. Always disconnect
the main power before attempting to change the gobos.
1. To change a gobo, rotate the moving head so that the UV
lens is located on top. Unscrew the single middle screw. See
instruction number 1 on the next page.
2. Once you loosen the single screw you are able to swing the
head back. See instruction number 2 on the next page. You
will now be able to access the gobo wheel. Turn the wheel
with your hand until you come across the gobo you would
like to change.
3. To remove the gobo holder gently pull the gobo holder to-
wards the front of the unit and slide it up and out.
4. Gently and carefully remove the retainer ring. After the re-
tainer ring is removed, carefully remove the gobo.
5. Change the gobo and replace the retainer ring. Carefully slide
the gobo holder back into the housing slot.
6. Reassemble the unit.
Focus Spot Two Changing the Gobo
