ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 34
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Focus Spot Two Specifications
Model: Focus Spot Two
Voltage: 100 - 240V, 50/60Hz
LED: 1 x 75W Cold White LED
1 x 3W UV LED
Power Consumption: 108W
Dimensions: 6.75”(L) x 9.25”(W) x 15.25”(H)
173mm x 237mm x 385mm
Weight: 16 Lbs. / 7.3 kgs.
Beam Angle: 15 ~ 20 Degrees
Gobo Size: 23.8mm (Outer)
19mm (Inner/Image)
0.2mm (Thickness)
Fuse: 2 Amp
Power Cord Daisy Chain: 14 Fixtures Max. (120V)
26 Fixtures Max. (230V)
Duty Cycle: None
DMX: 2 DMX Channel Modes: 16 Channel
Mode & 18 Channel Mode
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 2 Year (730 days)
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
The Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
