Using the SK 300 G4
136
Select a standard display
▷ Press the UP or DOWN buttons to select a standard display.
Frequency/Name standard display
►
Channel/Frequency standard display
►
Name/Channel standard display
►
ew300 G4
MHz
548.100
MUTE
P
AF
MHz
548.100
B.Ch: 20.12
MUTE
P
AF
B.Ch: 20.12
MUTE
P
AF
ew300 G4
