Kurzweil PC3A6 [149/423] Controller number
![Kurzweil PC3A7 [149/423] Controller number](/views2/2008894/page149/bg95.png)
Setup Mode
Controllers
7-23
Controller
Number
Corresponding
Destination
Name
Description
70–83 MIDI 70–83 MIDI Controllers 70–83
84 Portamen Portamento control, best with mono voices, value is relative to
key range, makes pitch momentarily slide to a note
85–90 MIDI 85–90 MIDI Controllers 85–90
91 GM Reverb With PC3A in General MIDI mode, controls Reverb send level
92 MIDI 92
93 GM Chorus With PC3A in General MIDI mode, controls Chorus send level
94-95 MIDI 94-95 MIDI Controllers 94–95
96 Data Inc Equivalent to pressing the plus button
97 Data Dec Equivalent to pressing the minus button
98 NRegParL Non-Registered Parameter Least Signicant Byte
99 NRegParM Non-Registered Parameter Most Signicant Byte
100 RegParL Registered Parameter Least Signicant Byte
101 RegParM Registered Parameter Most Signicant Byte
102-108 MIDI 102-108 MIDI Controllers 102–108
109 MIDI 109 Set’s arpeggiator velocity when ARPEGGIATOR velocity is set
to MIDI 109 mode
110-119 MIDI 110-119 MIDI Controllers 110–119
120 Sound Off Stops all sound in the corresponding channel
121 RstCtls Reset Controllers to defaults in the corresponding channel
122 Local
123 Notes Off Sends Note Off Message to all playing notes in the
corresponding channel
124 Poly
125 Omni
126 Mono On
127 Mono Off
128 Pitch Pitch—values above and below 64 bend the pitch up and
down, respectively
129 PitchRev Pitch—values above and below 64 bend the pitch down and
up, respectively
130 PitchUp Pitch—values above 0 bend the pitch up
131 PitchDwn Pitch—values above 0 bend the pitch down
132 Pressure Pressure
133 Tempo Tempo
134 KeyNum Triggers playback of notes by Key Number—e.g., C4 is 60
135 KeyVel Key Velocity
136 ProgInc Program Increment—increments current program number
137 ProgDec Program Decrement—decrements current program number
Table 7-4 Controller Destination List
