Introduction
How to Use This Manual
This PC3A Musician’s Guide describes how to connect and power up your PC3A, and to hook up
the PC3A to your sound system and MIDI system. It provides an overview of the front panel,
and a brief description of the operating modes to help you start playing music with the
instrument. It covers the PC3A in its 88, 76, and 61-note congurations (PC3A8, PC3A7, and
PC3A6).
Detailed information on editing and advanced programming features is also provided on the
Kurzweil website:
http://www.kurzweil.com
The best way to read this guide is with your PC3A in front of you. By trying the examples we give
to illustrate various functions, you can get a quick understanding of the basics.
Do I Have Everything?
Your PC3A shipping carton should include the following in addition to your instrument:
• Power cable
• Sustain pedal
• USB cable
• Getting Started manual
If you don’t have all of these components, please call your Kurzweil/Young Chang dealer.
You may also want to purchase a USB thumb drive for portable backups and storage.
Boot Loader
When you need to update the PC3A’s software or run diagnostic tests, you’ll use the Boot Loader.
To bring up the Boot Loader, hold down the Exit button (below the cursor buttons, to the right of
the display) while powering on your PC3A. Refer to Appendix BAppendix B, p.1 for details on
the Boot Loader.
Battery
The PC3A uses a CR2032 battery to power its clock. The battery should last ve years, and a
message will tell you when the battery needs replacing. The access panel on the bottom of the
PC3A (which you can easily remove with a screwdriver) allows you to get at the battery for
removal and replacement.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type (CR2032).
