Effects and Effect Mode
Effects Overview
DiBassG controls the gain of a bass-shelf lter on the dierence signal. By boosting the low
frequency components of the dierence signal, you can increase the sense of acoustic
envelopment. Range is -79.0 to 24.0 dB.
DiBassF is the transition frequency for the bass-shelf frequency. Range is 16 to 25088 Hz.
The processed signal is split into three frequency bands—Lo, Mid, and High—each of which can
be delayed and panned separately.
Crossover1 and 2 are the two Crossover frequencies at which the band-split lters split the signal
into three bands. The two parameters are interchangeable: either may have a higher frequency
than the other. Range is 16 to 25088 Hz.
Pan [High/Mid/Low] sets the pan position for each band. Range is -100% (fully left) to 100% (fully
right.)
Delay [High/Mid/Low] sets the delay for each band. Range is 0 to 1000 ms.
Stereo Image
This eect provides enhancement for a stereo signal. It also features a stereo correlation meter. It
uses some parameters from Mono to Stereo and some from Stereo Analyze (following).
