Kurzweil PC3A6 Руководство по эксплуатации онлайн [62/423] 777181
![Kurzweil PC3A6 Руководство по эксплуатации онлайн [62/423] 777181](/views2/2008894/page62/bg3e.png)
Program Mode
KB3 Program Structure
6-7
KB3 Mode Effects Buttons (Bank Buttons)
When using a KB3 program, the Bank buttons (above the sliders) control KB3 eects, instead of
choosing program banks as they usually do in program mode. The KB3 function is labeled below
each button, their LEDs indicate the status of the various eects for the current KB3 program.
This status is saved as part of each program. You can change the eects in real time by pressing
the buttons.
The KB3 eects return to their programmed settings the next time you select the program. If,
however, you’re in the Program Editor when you change the eects, you’re actually editing the
program. (EacheectalsohasacorrespondingparameterintheProgramEditor,seethetablebelow.) If
you like the changes, you can save the program with the new KB3 eects settings. If you don’t
like the changes, you can exit without saving, and the program will revert to its previous settings.
In KB3 mode the Bank buttons also respond to and send MIDI Controller messages. See Table 6-3
on page 6-8 for details.
Effect
Category
Button Name
LED Color
(relative to
button name/
state)
Corresponding
Page and
Parameter
Comments
Rotary
Fast / Slow red/green MISC: SpeedCtl
Vibrato
On / Off red/off MISC: VibChorCtl
Chorus / Vibrato red/green MISC: VibChorSel Disabled if Button 2 is off
Depth 1 / 2 / 3 green/orange/red MISC: VibChorSel Disabled if Button 2 is off
Percussion
On / Off red/off PERC: Percussion
Volume Loud / Soft red/green PERC: Volume Disabled if Button 5 is off
Decay Fast / Slow red/green PERC: Decay Disabled if Button 5 is off
Pitch High / Low red/green PERC: Harmonic Disabled if Button 5 is off
Table 6-2 KB3 Mode Effects Buttons and Corresponding Parameters
Additional Controller Assignments In KB3 Mode
Other default assignments for factory KB3 programs include:
CC Pedal 1 (volume) controls preamp volume, which emulates the volume control of an organ
preamp. The PreampResp parameter must be set to On for this to work (the default setting.) See
PreampResp on page 6-67 for details.
The Mod Wheel controls Distortion Drive.
Switch Pedal 1 (sustain) controls the SpeedCtl parameter, which toggles the Rotary speed
between slow or fast. See SpeedCtl on page 6-68 for details. This has the same eect as using Bank
Button 1 (labeled Rotary Fast/Slow.)
