Vizi BSW 300 Offset Menu
Gobo2 - Setting adjustment for gobo wheel 2.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “Gobo2” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
Prism - Setting adjustment for the 1st prism.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “Prism” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
Prism2 - Setting adjustment for the 2nd prism.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “Prism2” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
R-Prism - Setting adjustment for the rotating prism.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “R-Prsim” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
Angle/Frost - Setting adjustment for the frost lter.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “Angle/Frost” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
Vizi BSW 300 Offset Menu
then press ENTER to conrm. Press the MENU button for one second
to exit.
Focus - Setting adjustment for the focus.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that “Focus” is displayed, press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.
Vizi BSW 300 Error Information
If any of these warning’s appear and you are not certain on what form
of action needs to be taken, please contact ADJ customer support
for more information.
Temp. Sense Error
This will appear when the temperature check board is damaged.
CPU-8 Error, CPU-C Error, CPU-D Error
This will appear when the PC board or wires are damaged.
Memory Initial Fail
This will appear when the memory IC is damaged.
Temperature Sense Error
This will appear when the temperature check board is damaged.
Random Error Messages
Pan Reset Error, Pan Encode Error, Tilt Reset Error, Tilt Encode
Error, Shutter Reset Fail, Dimmer Reset Fail, Color Reset Fail, Gobo
Reset Fail, R-Gobo1 Reset Fail, Gobo2 Reset Fail, Prism Reset Fail,
R-Prism Reset Fail, Prism2 Reset Fail, Focus Reset Fail, Angle/Frost
Reset Fail.
These Error messages may appear when turning on or reseting the
unit. Please contact ADJ customer support.
