![AMERICAN DJ Vizi BSW300 [22/22] Model vizi bsw 300](/views2/2009553/page22/bg16.png)
ADJ Products, LLC - www.adj.com - Vizi BSW 300 Instruction Manual Page 42
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
The Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Model: Vizi BSW 300
Voltage: 100~240V, 50/60Hz
LED: 1 x 300W White LED
Color Temperature: 8000K
Life Expectancy: 50000 Hours
CRI: 70
Power Cord Daisy Chain: 4 Fixtures Max. (120V)
8 Fixtures Max. (230V)
Power Consumption: 345W, 2.851 Amps @ 120V, 60Hz
338W, 1.525 Amps @ 130V, 50Hz
Beam Angle: 1-7 Degree Beam Angle (Beam)
8-17 Degree Beam Angle (Spot)
18-26 Degree Beam Angle (Wash)
Dimensions: 12.75”(L) x 14.75”(W) x 21.5”(H)
325mm x 376mm x 545mm
Weight: 49 Lbs. / 22 kgs.
Colors: 14 + White (2 Separate Color
Wheels, 7 Color’s for each wheel +
White on each wheel)
Gobos: - 3 Glass & 4 Metal Replaceable
Rotating Gobo’s + Spot (1st Gobo
Wheel)
- 6 Fixed Gobo’s + Spot & 3 Variably
Sized Beam Aperture’s (2nd Gobo
Wheel)
Replaceable Gobos: 26.9mm (18mm Viewable)
0.3mm (Thickness Metal Gobo)
1.1mm (Thickness Glass Gobo’s)
Pan: 540 Degrees
Tilt: 240 Degrees
Strobe Rate: 0.3 to 20Hz
Flicker Free: 1.2KHz
Fuse: 10A
DMX: 2 DMX Channel Modes: 17 & 20
Power Cable: 1.5M Neutrik powerCON Cable
Warranty: 2 Year (730 days)
Vizi BSW 300 Specifications
Please Note: Specications and improvements in the design of this unit and
this manual are subject to change without any prior written notice.
