ADJ Products, LLC - www.adj.com - Vizi BSW 300 Instruction Manual Page 15ADJ Products, LLC - www.adj.com - Vizi BSW 300 Instruction Manual Page 14
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller. A DMX controller allows you to create unique
programs tailored to your individual needs.
1. The Vizi BSW 300 has 2 DMX channel modes; an 17 channel
mode and 20 channel mode. See pages 15-22 for detailed
description of the DMX traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 11-13 as well as the set-up specifications that are
included with your DMX controller.
3. Follow the instructions on page 24 to select your desired DMX
channel mode and DMX address.
4. Use the controller’s faders to control the various DMX fixture traits.
5. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
6. For help operating in DMX mode consult the manual included
with your DMX controller.
Vizi BSW 300 DMX Control Vizi BSW 300 17 Channel Mode
Channel Value Function
1 0 - 255 PAN MOVEMENT
2 0 - 255 TILT MOVEMENT
3 COLOR WHEEL 1
0 - 7 WHITE
8 - 15 RED
16 - 23 BLUE
24 - 31 LIGHT GREEN
32 - 39 YELLOW
40 - 47 ORANGE
48 - 55 MAGENTA
56 - 64 LIGHT BLUE
65 - 127 COLOR INDEXING
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 STOP
194 - 255 COUNTER-CLOCKWISE ROTATION SLOW - FAST
4 COLOR WHEEL 2
0 - 7 WHITE
8 - 15 PINK
16 - 23 CTO 3200K
24 - 31 UV PURPLE
32 - 39 YELLOW
40 - 47 GREEN
48 - 55 CTO 5600K
56 - 64 CYAN
65 - 127 COLOR INDEXING
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 STOP
194 - 255 COUNTER-CLOCKWISE ROTATION SLOW - FAST
5 GOBO WHEEL 1 (GLASS GOBO’S)
0 - 10 OPEN
11 - 21 GOBO 1
22 - 32 GOBO 2
33 - 43 GOBO 3
44 - 54 GOBO 4
55 - 65 GOBO 5
66 - 76 GOBO 6
77 - 87 GOBO 7
88 - 127 GOBO SHAKE GOBOS 1-7
128 - 189 COUNTER-CLOCKWISE ROTATION FAST - SLOW
190 - 193 NO ROTATION
