English
3
X570 Phantom Gaming X
AMD Ryzen series CPUs (Pinnacle Ridge)
•
3 x PCI Express x16 Slots (PCIE1/PCIE3/PCIE5: single at
Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE3);
triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE3) / Gen4x4
(PCIE5))*
AMD Ryzen series CPUs (Picasso)
•
1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE1))*
•
1 x PCI Express 4.0 x16 Slot (single at x4 (PCIE5))*
* Supports NVMe SSD as boot disks
•
2 x PCI Express 4.0 x1 Slots
•
Supports AMD Quad CrossFireX
TM
, 3-Way CrossFireX
TM
and CrossFireX
TM
•
Supports NVIDIA® Quad SLI
TM
and SLI
TM**
•
Supports NVIDIA® NVLink
TM
with dual NVIDIA® GeForce®
RTX series graphics cards**
** NVIDIA NVLink Bridge does not come with the package.
Please purchase it from NVIDIA® if necessary.
** is feature is only supported with Ryzen Series CPUs
(Pinnacle Ridge).
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ax module (on the rear I/O)
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
Supports HDMI 2.0 with max. resolution up to 4K x 2K
(4096x2160) @ 30Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant
HDMI monitor is required)
•
Supports HDR (High Dynamic Range) with HDMI 2.0
•
Supports HDCP 2.2
with HDMI 2.0 Port
•
Supports 4K Ultra HD (UHD) playback with HDMI 2.0 Port
•
Supports Microso PlayReady®
