ASRock AMD X570 SAM4 ATX X570 PHANTOM GAMING X [34/110] English
![ASRock AMD X570 SAM4 ATX X570 PHANTOM GAMING X [34/110] English](/views2/2013080/page34/bg22.png)
English
27
X570 Phantom Gaming X
Ryzen Series CPUs (Picasso):
x=1 or 2
SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label
DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM module label
UDIMM/SO-DIMMs Memory Slot
# of DIMMs on
the Channel
# of Ranks
per DIMM
1.20V
1 of 1 xR
SR: 2933
DR: 2677
1 of 2 xR-0
SR: 2667
DR: 2400
2 of 2 1R-1R 2133
2 of 2 2R-xR 1866
