ASRock AMD X570 SAM4 ATX X570 PHANTOM GAMING X [84/110] Main screen
![ASRock AMD X570 SAM4 ATX X570 PHANTOM GAMING X [84/110] Main screen](/views2/2013080/page84/bg54.png)
English
77
X570 Phantom Gaming X
4.2 Main Screen
When you enter the UEFI SETUP UTILITY, the Main screen will appear and
display the system overview.
