8
EN
electric shock. Damaging a gas line can lead
to explosion. Penetrating a water line causes
property damage.
• Do not operate the power tool stationary. It
is not designed for operation with a saw table.
• Do not use high speed steel (HSS) saw
blades. Such saw blades can easily break.
• Do not saw ferrous metals. Red hot chips can
ignite the dust extraction.
• When working with the machine, always
hold it firmly with both hands and provide
for a secure stance. The power tool is guided
more secure with both hands.
• Secure the workpiece. A workpiece clamped
with clamping devices or in a vice is held more
secure than by hand.
• Always wait until the machine has come to
a complete stop before placing it down. The
tool insert can jam and lead to loss of control
over the power tool.
• Circular saws are intended to cut wood or
wood-like products, they cannot be used
with abrasive cut-off wheels for cutting
ferrous material such as bars, rods, studs,
etc. Abrasive dust causes moving parts
such as the lower guard to jam. Sparks from
abrasive cutting will burn the lower guard, the
kerf insert and other plastic parts.
• Use only saw blades that are marked with
a speed equal or higher than the speed
marked on the machine.
• Only use saw blades that match the
specifications given in this operating
manual and that have been tested and
marked in accordance with EN 847-1.
2. MACHINE INFORMATION
Intended use
This cordless circular saw is intended for
lengthwise, crosswise and bevel cutting in wood
while keeping the baseplate resting firmly on
the workpiece. Sawing plastics or metals is not
permitted.
The power tool with the fitted sawblade is designed
with sufficient capacity for sawing hardwood and
softwood as well as chipboard and fibreboard. The
sawblade is not designed for cutting firewood. Do
not use the saw to cut materials other than those
specified described in manual.
TECHNICAL SPECIFICATIONS
Model No. CSM1049
Voltage 20V
No load speed 4000 /min
Saw blade size Ø165×Ø16×1.5mm
Sawing capacity 0° 45mm
Sawing capacity 45° 30mm
Weight 2.3 kg
Sound pressure level L
PA
82.3 dB(A), K=3dB(A)
Sound power level L
WA
93.3 dB(A), K=3dB(A)
Main grip a
h,w
0.877 m/s
2
K=1.5m/s
2
Auxiliary grip a
h,w
1.002 m/s
2
K=1.5m/s
2
Only use the following batteries of the FX-POWER
20V battery platform. Using any other batteries
could cause serious injury or damage the tool.
CDA1167 20V, 2Ah Lithium-Ion
CDA1168 20V, 4Ah Lithium-Ion
The following charger of the can be used to
charge these batteries.
CDA1169 Charger adapter
CDA1170 Quick charger
CDA1172 Quick charger
The batteries of the FX-POWER 20V battery
platform are interchangeable with all the FERM
FX-POWER battery platform tools.
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with
a standardized test given in EN62841; it may be
used to compare one tool with another and as a
preliminary assessment of exposure to vibration
when using the tool for the applications mentioned.
• Using the tool for different applications, or with
different or poorly maintained accessories,
may significantly increase the exposure level.
• The times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
