FERM CSM1043 [9/148] Assembly
![FERM CSM1043 [9/148] Assembly](/views2/2015739/page9/bg9.png)
9
EN
c) Do not position your body in line with the rotating
wheel. Kickback will propel the tool in direction
opposite to the wheel’s movement at the point of
snagging.
d) Use special care when working corners, sharp
edges etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing
have a tendency to snag the rotating accessory
and cause loss of control or kickback.
e) Do not attach a saw chain, woodcarving blade,
segmented diamond wheel with a peripheral
gap greater than 10 mm or toothed saw blade.
Such blades create frequent kickback and loss of
control.
f) Do not “jam” the wheel or apply excessive
pressure. Do not attempt to make an excessive
depth of cut. Overstressing the wheel increases
the loading and susceptibility to twisting or
binding of the wheel in the cut and the possibility
of kickback or wheel breakage.
g) When wheel is binding or when interrupting a cut
for any reason, switch off the power tool and hold
the power tool motionless until the wheel comes
to a complete stop. Never attempt to remove the
wheel from the cut while the wheel is in motion
otherwise kickback may occur. Investigate and
take corrective action to eliminate the cause of
wheel binding.
h) Do not restart the cutting operation in the
workpiece. Let the wheel reach full speed and
carefully re-enter the cut. The wheel may bind,
walk up or kickback if the power tool is restarted
in the workpiece.
i) Support panels or any oversized workpiece to
minimize the risk of wheel pinching and kickback.
Large workpieces tend to sag under their own
weight. Supports must be placed under the
workpiece near the line of cut and near the edge
of the workpiece on both sides of the wheel.
j) Use extra caution when making a “pocket cut”
into existing walls or other blind areas. The
protruding wheel may cut gas or water pipes,
electrical wiring or objects that can cause
kickback.
Be careful at all times!
Immediately switch off the machine when:
• The plug or power cord is defective or
damaged.
• The switch is defective.
• You smell smoke or burning insulation
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the power supply
corresponds to the voltage on the rating
plate.
Class ll machine. Your machine is double
insulated; therefore no earthwire is
required.
If the replacement of the supply cord is necessary,
this has to be done by the manufacturer or his
agent in order to avoid a safety hazard.
Using extension cables
Only use an approved extension cable suitable
for the power input of the machine. The minimum
conductor size is 1.5 mm². When using a cable
reel always unwind the reel completely.
3. ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug
from the mains.
Mounting the handle
Fig. 2
• Mount the handle (2) to the metal part on the
machine as shown in Fig. 2.
• Fix the Cap nut (11) tightly using a wrench.
Attachment of the parallel guide
Fig. 3
• Attach the parallel guide (12) on the right side
of the machine, as shown in Fig. 3
• Lock the guide down by turning the
adjustment knob (13) clockwise.
