TURNING ON THE HEATER (see picture 1-4)
Plug the electric cable into the outlet.
Rotate the knob to the required position:
g. 1 - o
g. 2 - Medium capacity
g. 3 - Maximum capacity
Switching o the heater
Turn the switch to its "0" position.
Regulating the thermostat
The temperature in the room may be set by
means of the control knob (Fig. 4). Once the
pre-set temperature is produced, the thermostat
will automatically switch the heating elements
o while the fan will continue to operate thus
protecting the appliance from overheating. If
the temperature falls down beyond the pre-
set value, the system will switch the heating
elements on again.
SECURITY SYSTEM:
• The fan heater is equipped with overheating
shut-o which switchs, if the temperature
inside the appliance exceeds the normal
running temperature heating element
product will automatically stop working, the
motor will continue to operate, the internal
heat shed. This protective device applies only
to the appliance itself and has no inuence
on room temperature regulation.
• If overheating occurs, remove the plug
from socket, push buttons to switch the
convector o and let it cool down for at least
10 minutes. Put the plug in the socket and
switch the heater on.
• If you still notice the same defect above
mentioned remove the plug from socket and
have the convector serviced by authorized
service personal only.
MAINTENANCE:
• The fan heater only needs regular cleaning
on the outside.
• Before you clean the unit, turn the switch to
OFF. Remove the plug from socket and wait
until the fan heater cool down.
• Use a damp cloth to wipe the heater housing.
• Do not use water, detergents, abrasive
cleaning liquids or chemical agents (alcohol,
gasoline etc.) to clean the unit.
TECHNICAL CHARACTERISTICS
220-240 V • 50 Hz • 3000 W
This marking indicates that this product
should not be disposed with other
household wastes throughout the EU. To
prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environmental safe recycling.
3
ENGLISH
2
ENGLISH
INSTRUCTION MANUAL
This product is only suitable for well
insulated spaces or occasional use.
• Thank you very much for your purchase of
our Fan heater.
• Please read the instruction manual carefully
and keep it for future use.
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electrical shock, burns
and other injury, including the following:
1. Study this instruction manual carefully
before using the product.
2. The device is only intended for private and
not for any commercial use.
3. Remove the unit from its packaging and
check to make sure it is in good condition
before using.
4. Do not let children play with parts of the
packing (such as plastic bags).
5. Check the household voltage to ensure it
matches the fan’s rated specication.
6. Check the power cord and plug carefully
before use to make sure that they are not
damaged.
7. Before unplugging the power cord, be sure
to turn o the power. When touching the
unit, be sure your hands are dry to prevent
from electric shock.
8. Do not use near or point the heater to
furniture, curtains or other inammable
objects. Keep back of fan heater min. 15cm
away from walls or objects to allow free
airow.
9. Do not block air intakes or exhaust in any
manner to prevent a possible re.
10. Do not use or leave the fan heater
unattended when children, old or disabled
people are present.
11. Always unplug heater when not in use.
12. Prevent water from getting into the housing
of the heater during operation or in storage.
Hazard of electric shock. Always store in dry
area with no moisture.
13. Do not use in places where there are gas,
paint or other inammable goods and
objects
14. This heater is not intended for use in
bathrooms, laundry areas and similar indoor
locations. Never locate the heater where it
may fall into a bath tub or other bodies of
water.
15. Do not run the cord under carpeting. Do not
cover cord with throw rugs,runners or the
like. Arrange cord away from trac area and
where it will not be tripped over.
16. Do not use a soft surface, like a bed, where
openings may become blocked.
17. Use this heater only as described in this
manual. Any other uses not recommended
by the manufacturer may cause re, electric
shock, or injury to persons and may void
warranty.
18. Avoid the use of an extension cord because
the extension cord may overheat and cause a
risk of re.
19. Do not use outdoors.
20. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
21. Children should be supervised to ensure that
they do not play with the appliance.
CAUTIONS
• This appliance is not a toy.
• This appliance is for household use only.
• Do not immerse the unit in the water.
• To avoid the risk of re or electric shock do
not remove the housing by yourself.
• Any servicing other than cleaning and user
maintenance should be performed by an
authorized service representative.
• If the supply cord is damaged, it must be
replaced by a special cord or assembly
available from the manufacturer or its service
agent.
• Repair should be done by an authorized
service personal only.
Warning: In order to avoid overheating
DO NOT COVER the heater
Do not use this heater in the immediate
surroundings of a bath, a shower or a
Swimming pool.
PARTS DESCRIPTION (see picture A)
1) Protective grid front
2) Heating element
3) Handle
4) Shell
5) Foot
6) Motor
7) Power line
8) Switch
9) Thermostat
Modell FA-5565
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat
output
P
nom
3,0 KW manual heat charge control, with integrated
thermostat
NA
Minimum heat
output (indicative)
P
min
0,04 KW manual heat charge control with room and/or
outdoor temperature feedback
NA
Maximum
continuous heat
output
P
max
3,0 KW electronic heat charge control with room and/
or outdoor temperature feedback
NA
At nominal heat output Fan assisted heat output NA
At nominal heat
output
el
max
0,000 KW Type of heat output/room temperature control (select one)
At minimum heat
output
el
min
0,000 KW single stage heat output and no room
temperature control
[no]
In standby mode el
SB
0,000 KW Two or more manual stages, no room
temperature control
[no]
Contact details TIMETRON Raimundgasse 1/8, A-1020 Vienna, Austria
