Elica NIKOLATESLA PRIME S BL/A/83 [19/360] Using the hob fit

Note: the setting must be made with the hob switched off,

without pressing the

ON/OFF (1) button, when the hob

is connected to the mains, or reconnected to the mains,

within the next 2 minutes.

To set the Power Limitation:

• press

(which will flash, only for the first 2 minutes

after the product has been switched on)

• while continuing to hold down

, press, one at a

time, all the Selection/Display areas (2) of the cooking

zones in a counter-clockwise direction starting from the

front left zone (FR); a short acoustic signal will be emitted

with each press and when all the Displays (2) have been

pressed, it will be possible to release the key:

at this point, the Display (2) of the rear left zone (RL) will

show, in alternating sequence, the symbols

and ,

indicating that the setting can be made.

• select the Display (RL-2) then slide along the Selection

bar (3), until the Display shows the symbols

and ;

The Display (FL-2) will show the current setting with the

values in the table:

Displayed value Power (Kw)

7.4 Kw (default setting)

4.5 Kw

3.1 Kw

To change the Power Limitation setting:

• press the Display (FL-2) then slide along the Selection

bar (3), to

set the new setting. To save the selection made, press the

ON/OFF (1) button for 2 seconds; an extended audible

signal will be emitted to confirm the setting.

● Key Lock

The Key Lock allows you to lock the settings of the hob to

prevent accidental tampering with the same, while leaving

the set functions enabled.

Activation:

• press

(10) Repeat the operation to deactivate.

Note: if any other function is pressed while the Key Lock is

active, the symbol

will flash to indicate that the function

is in use and must be deactivated if necessary in order to

use the hob.

● Automatic Heat UP

The Automatic Heat UP function allows the set power to be

reached more quickly; with this function it is possible to

cook food faster without the risk of burning it, insofar as the

temperature does not exceed the set level. This function is

available for power levels from

to .

Activation:

• with the cooking zone on, press

(7), the Display (2)

will show a flashing

, alternating with the power set in

the cooking zone.

By increasing the power level of the cooking zone: the

Automatic Heat Up function remains active, with the new

temperature setting;

By decreasing the power level of the cooking zone: the

Automatic Heat Up function is deactivated.

Note: by selecting another cooking zone at the same time,

the symbol

(7) will go back to being illuminated with

light intensity, and it will be possible to proceed, also for

this zone, with the activation of the function; in any case,

the function remains active in the zone in which it has

already been set, as indicated in the Display (2).

● Pause

The Pause function allows active functions on the hob to be

suspended, bringing the cooking power to zero.

Activation:

• press

(9), the symbol will flash on the display (2)

To deactivate the function:

• press

(9) the Selection bar (3) will light up

• press/slide on the Selection Bar (3) to deactivate the

function.

Note: deactivation restores the conditions of the hob before

the pause; the hob continues to work with the same

settings previously set.

Note: if after 10 minutes, the Pause Function is not

deactivated, the hob will turn off automatically.

Note: the Pause Function does not affect the extraction.

● “STAND ALONE” Timer

The Timer function is a countdown independent of the

cooking zones (and the extraction zone).

The Timer is activated by pressing the Zone/Display (4).

Use the symbols

(5) to set the duration of the

Timer, which is shown in the Zone/Display (4)

Note: wait 10 seconds without pressing any other

command, so that the countdown starts.
