Aligning the Fine Scale (see figure N)
Bring the power tool into the chop and mitre saw working
position. (see “Working Position”, page 43)
Turn the saw table 22 to the 0° detent 27. The lever 26
must be felt to engage in the detent.
Checking:
The 0° mark of the fine scale 46 must be in alignment with the
0° mark of the scale 23.
Adjusting:
Remove the insert plate 24.
Loosen the screw 55 with the slotted screwdriver provid-
ed and align the fine scale alongside the 0° marks.
Retighten the screw again.
Aligning the Angle Indicator (Vertically)
(see figure O)
Bring the power tool into the chop and mitre saw working
position. (see “Working Position”, page 43)
Turn the saw table 22 to the 0° detent 27. The lever 26
must be felt to engage in the detent.
Checking:
The angle indicator 47 must be in alignment with the 0° mark
of the scale 48.
Adjusting:
Loosen the screw 56 with the slotted screwdriver provid-
ed and align the angle indicator alongside the 0° mark.
Afterwards, check to ensure that the adjustment made is
correct for the 45° mark.
Retighten the screw again.
Aligning the Fence
Bring the power tool into the table saw working position.
(see “Working Position”, page 48)
Turn the saw table 22 to the 0° detent 27. The lever 26
must be felt to engage in the detent.
Checking: (see figure P1)
Adjust an angle gauge to 90° and position it between the
fence 30 and the saw blade 7 on the saw table 22.
The leg of the angle gauge must be flush with the fence over
the complete length.
Adjusting: (see figure P2)
Loosen all hex socket screws 39 with the hex key 5 provid-
ed.
Turn the fence 30 until the angle gauge is flush over the
complete length.
Retighten the screws again.
Setting the Standard Bevel Angle 0° (Vertical)
Bring the power tool into the table saw working position.
(see “Working Position”, page 48)
Turn the saw table 22
to the 0° detent 27. T
he lever 26
must be felt to engage in the detent.
Checking: (see figure Q1)
Adjust an angle gauge to 90° and position it on the saw ta-
ble 22.
The leg of the angle gauge must be flush with the saw blade 7
over the complete length.
Adjusting: (see figure Q2)
Loosen the nut (size 10 mm) of the Allen screw 57.
Screw the Allen screw 57 with a suitable Allen wrench (size
3 mm) in or out until the leg of the angle gauge is flush with
the saw blade over the complete length.
Retighten the nut again.
In case the angle indicator 47 is not in a line with the 0° mark
of the scale 48 after the adjustment, the angle indicator must
be aligned accordingly (see “Aligning the Angle Indicator (Ver-
tically)”, page 47).
Setting the Standard Bevel Angle 45° (Vertical)
Bring the power tool into the table saw working position.
(see “Working Position”, page 48)
Turn the saw table 22 to the 0° detent 27. The lever 26
must be felt to engage in the detent.
Loosen the lock lever 37 and tilt the tool arm leftward to
the stop (45°) by the handle 18.
Checking: (see figure R1)
Adjust an angle gauge to 45° and position it on the saw ta-
ble 22.
The leg of the angle gauge must be flush with the saw blade 7
over the complete length.
Adjusting: (see figure R2)
Loosen the nut (size 10 mm) of the Allen screw 58.
Screw the Allen screw 58 with a suitable Allen wrench (size
3 mm) in or out until the leg of the angle gauge is flush with
the saw blade over the complete length.
Retighten the nut again.
In case the angle indicator 47 is not in a line with the 45° mark
of the scale 48, firstly check the 0° setting for the bevel angle
and the angle indicator again. Then repeat the adjustment of
the 45° bevel angle.
Setting the Standard Bevel Angle 33.9° (Vertical)
Bring the power tool into the table saw working position.
(see “Working Position”, page 48)
Turn the saw table 22 to the 0° detent 27. The lever 26
must be felt to engage in the detent.
Loosen the lock lever 37.
Push the stop bolt 33
completely inside and swivel the tool
ar
m until the bolt faces against the stop screw 32.
Checking: (see figure S1)
Adjust an angle gauge to 33.9° and position it on the saw
table 22.
The leg of the angle gauge must be flush with the saw blade 7
over the complete length.
Adjusting: (see figure S2)
Loosen the nut (size 10 mm) of the stop screw 32.
Screw the stop screw with a suitable spanner (size 10 mm)
in or out until the leg of the angle gauge is flush with the saw
blade over the complete length.
Retighten the nut again.
