18 | English
– Remove the screws (17).
– Place the retaining clip (16) and the adapter (34) in the
setting gauge (19). The retaining clip (16) must slot into
the groove on the setting gauge (see figure R).
– Push the HM/TC planer blade (20) into the adapter (34)
from the side. The ridge on the adapter (34) must slot
into the groove on the HM/TC planer blade (see figure R).
– Tighten the screws (17).
– Insert the retaining clip (16) together with the adapter
(34) and the planer blade (15) into the blade head (13)
and/or the guide groove (14).
– Put the clamping jaw (12) on and insert the fastening
screws (11), which do not yet need to be screwed in
tightly.
– The planer blade must be fitted and aligned with the
centre of the planer base plate (8). Then tighten the
three fastening screws (11) using the Torx key (10), fol-
lowing the tightening sequence (①②③) specified on
the clamping jaw (12).
Changing from HM/TC to HSS
Planers fitted with HM/TC planer blades can be changed
over to HSS planer blades.
– Unscrew the three fastening screws (11) using the Torx
key (10) and remove the clamping jaw (12).
– Push the retaining clip (16) together with the planer
blade (15) and/or the HM/TC adapter (34) out of the
blade head (13).
– Remove the screws (17).
– Fit the assembled HSS planer blade (see " Fitting the
Planer Blades (see figures E–F)", page17) and align it
with the centre of the planer base plate (8).
– Put the clamping jaw (12) on and tighten the three
fastening screws (11) using the Torx key (10), following
the tightening sequence (①②③) specified on the
clamping jaw (12).
Dust/Chip Extraction
The dust from materials such as lead paint, some types of
wood, minerals and metal can be harmful to human health.
Touching or breathing in this dust can trigger allergic reac-
tions and/or cause respiratory illnesses in the user or in
people in the near vicinity.
Certain dusts, such as oak or beech dust, are classified as
carcinogenic, especially in conjunction with wood treatment
additives (chromate, wood preservative). Materials contain-
ing asbestos may only be machined by specialists.
– Use a dust extraction system that is suitable for the ma-
terial wherever possible.
– Provide good ventilation at the workplace.
– It is advisable to wear a P2 filter class breathing mask.
The regulations on the material being machined that apply in
the country of use must be observed.
u Avoid dust accumulation at the workplace. Dust can
easily ignite.
Clean the chip ejector (3) regularly. Clean a clogged chip
ejector using a suitable tool, e.g. a piece of wood, com-
pressed air, etc.
u Do not allow the chip ejector to come into contact with
your hands. You may be injured by rotating parts.
Always use an external dust extraction device or chip/dust
bag to guarantee optimum suction.
Operation
Start-up
u Pay attention to the mains voltage. The voltage of the
power source must match the voltage specified on the
rating plate of the power tool. Power tools marked
with 230V can also be operated with 220V.
u Products that are only sold in AUS and NZ: Use a resid-
ual current device (RCD) with a nominal residual current
of 30 mA or less.
Setting the cutting depth
Using the knob (2), the cutting depth can be continuously
adjusted between 0–2,6mm with the aid of the cutting
depth scale (1) (scale division=0,1 mm).
Switching on/off
u Make sure that you are able to press the On/Off switch
without releasing the handle.
To start the power tool, first press the lock-off switch(4),
then press and hold the on/off switch(5).
To switch off the power tool, release the on/off switch(5).
Note: For safety reasons, the on/off switch(5) cannot be
locked; it must remain pressed during the entire operation.
Practical advice
u Pull the plug out of the socket before carrying out any
work on the power tool.
Parking Rest (see figure N)
The parking rest (29) makes it possible to put down the
power tool directly after working, without any danger of
damaging the workpiece or the planer blades. During the
work process, the parking rest (29) is raised and the rear
section of the planer base plate (8) is uncovered.
Planing Procedure (see figure N)
Set the required cutting depth and position the power tool
with the front section of the planer base plate (8) on the
workpiece.
u Only bring the power tool into contact with the work-
piece when switched on. Otherwise there is danger of
kickback if the cutting tool jams in the workpiece.
Switch on the power tool and guide it over the surface of the
workpiece, applying uniform feed.
To achieve high-quality surfaces, apply only a low feed rate
and exert pressure on the middle of the planer base plate.
1 609 92A 4LE | (25.03.2021) Bosch Power Tools
