© SAMSUNG Electronics Co., Ltd. Page 87
CONVENIENT FEATURES
Retrieving the parked call
1.
Press the
[PARK]
button
or dial
[1] [0]
,
and enter the announced number.
You can also enter the announced number
after selecting
[PARK]
from the LCD screen.
2.
You will be connected to the Parked call.
- If the parked call is not retrieved within the pre-programmed time, the parked call will
recall to your
digital phone, an amber light will blink slowly on the Call or trunk button LED.
You cannot park and page intercom calls.
NOTE
